It's a Cali style conversion. This uses a Type 1 fanshroud. If you look at the engine in the Oval this is the same. From memory there is a bookletIt's a Cali style conversion. This uses a Type 1 fanshroud. If you look at the engine in the Oval this is the same. From memory there is a booklet you can buy from the guy who originally thought of the conversion. rustyovali might be able to tell you more. AFAIK you need to modify the cylinder tin to fit and make / buy a generator stand and pulley to suit. The other way you can go is what I've done on my Type 4 which is to use a Porsche fan and glass shroud. There used to be a company here in Aus who did these - #Sharpbuilt Pretty sure he's still making them. If not you might be able to pick one up second hand. More ...
-
Hi Rusty,thanks for the kind words re the panel.The kombi is using a Sharpbuilt kit, http://www.sharpbuilt.com.au/sharpbuilt1/page11.htm,very much aHi Rusty,thanks for the kind words re the panel.The kombi is using a Sharpbuilt kit, http://www.sharpbuilt.com.au/sharpbuilt1/page11.htm,very much a Cali style conversion.My Oval is using a DTM fan shroud.The book Mick is referring to is "The Type4 conversion manual" its well worth a read and you can get it here- http://www.nextgen-usa.com/ Once you go Typ4 there will be no going back! More ... -
Thanks for the info and links Nick, I have been doing a fair bit of reading on the type 4 conversion lately and have read there is some clearanceThanks for the info and links Nick, I have been doing a fair bit of reading on the type 4 conversion lately and have read there is some clearance issues with the exhausts on lowered busses. What exhaust are you running and have you had any dramas with it scraping? More ...
-
Hi mate,I'm using a CSP python.The header pipes are probably around 30mm lower than the sump and the muffler tip is 120mm from the road.I had toHi mate,I'm using a CSP python.The header pipes are probably around 30mm lower than the sump and the muffler tip is 120mm from the road.I had to modify the muffler to clear my shocks,no big deal.I'm not super low but I've had no scraping issues at all.Before I put the CE steering rack on the front was scraping ALL the time.I guess my bus is lowered 120mm all round.Exhausts are the one of the spendy bits with a Typ4 but these motors are really sensitive to the exhaust set up so its not really something you should scrimp on.I'm running an A1 sidewinder on my oval{2718cc Typ4} and I can say the quality of the CSP is miles ahead,much bigger and thicker flanges than the A1. More ...
-
Have a look at my build thread,there's a good shot of the exhaust- http://vdubber.com/blogs/entry/nicks-57-bottomless-money-pit-part-2
